If the ZERO backlash cannot be obtained, turn the differential bearing adjuster nut into the 8. While holding the ring gear against the pinion, turn the differential bearing adjuster nut out from the axle housing using the J 24429 until it contacts the differential side bearing. See 9. Turn the adjuster nut out from the axle housing an additional 2 slots using the J 24429 in order to obtain the initial backlash adjustment. See Special Tools. 10. Install the adjuster nut lock and the adjuster nut lock bolt. 11. Remove the left side differential bearing cap bolts. 12. Remove the left side differential bearing cap. Fig. 257: J 22779 13. Install the J 22779 into the left side axle housing between the differential bearing bore and
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
