Check the sealing surface of the pinion flange/yoke for nicks, burrs or rough tool marks that Check for worn or broken parts and replace as necessary. REAR AXLE HOUSING INSPECTION Carefully and thoroughly inspect all drive unit parts before assembly. Thorough inspection of the Inspect for nicks or burrs that could prevent the outer diameter of the pinion seal from Inspect the bearing cup bores for nicks or burrs. Remove any burrs that are found. Inspect the housing for cracks. Replace the housing if any cracks are found. Inspect the housing for foreign material such as metal chips, dirt, or rust. SHIMS INSPECTION Inspect the shims for cracks and chips. Replace the damaged shims. PINION DEPTH ADJUSTMENT (10.5 INCH AXLE) 1. Install the differential, if necessary. Refer to Differential Replacement (8.6, 9.5/9.5LD Inch Axles) or Differential Replacement (10.5 Inch, 11.5 Inch Axle). 2. Install the original shim to the pinion bearing retainer. If the original shim is not available, install a 0.41 mm (0.016 in) shim to build pinion depth. IMPORTANT: Do not reinstall the original cast iron production shims, if If service shims were previously installed, the shims can be IMPORTANT: Measure and record the thickness of the pinion gear bearing retainer shim before any service procedures are performed
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
