4. Install the differential pinion gears and pinion gear thrust washers by performing the following steps: 1. Position one pinion gear between the differential side gears. 2. Position the second pinion gear between the differential side gears directly opposite the of the first gear. 3. Rotate the differential side gears until the pinion gears is directly opposite the opening in the differential case. 4. Install the thrust washers. Rotate the pinion gears toward the differential opening in order to permit the sliding in 5. Install the pinion shaft. 6. Install a new pinion shaft lock bolt. Tighten: Tighten the new pinion shaft lock bolt to 36 N.m (27 lb ft). NOTE: Refer to Fastener Notice . IMPORTANT: The mating surface of the ring gear and the differential case must be clean and free of burrs before installing the ring
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
