Tighten: Tighten the pinion nut until the pinion end play is just taken up. Rotate the pinion 17. Remove the J 8614-01 . 18. Install the original shim to the pinion bearing retainer. If the original shim is not available, install a 0.41 mm (0.016 in) shim to build pinion depth. 19. Install the pinion gear bearing retainer to the axle housing. 20. Install the pinion bearing retainer bolts. Tighten: Tighten the pinion gear retainer bolts to 88 N.m (65 lb ft). Fig. 178: Measuring Pinion Rotating Torque 21. Using an inch-pound torque wrench, measure the rotating torque of the pinion. IMPORTANT: Do not apply sealant to the pinion gear bearing retainer at this time.
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
