2. Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . 3. Remove the rear cover and gasket. Refer to Rear Axle Housing Cover and Gasket Replacement. 4. Remove the pinion shaft locking bolt. Fig. 63: View Of Pinion Shaft 5. On axles without a locking differential, remove the pinion shaft.
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Rear Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
