Fig. 199: Using J 36601-3 & J 29763 To Measure Lowest Point In Differential Side 13. Install the adjustment screw and the lock nut of theJ 29763 (2) to the J 36601-4 or the J 36601-3. See Special Tools. 14. Install the J 29763 to the adjustment screw and lock nut assembly. See Special Tools. Tighten the lock nut to hold the J 29763 in place. See Special Tools. IMPORTANT: The left side differential bearing adjuster assembly on the 9.25 inch axle must be removed prior to placing the J 36601-3
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
