Excessive wear 3. Inspect the pinion gear splines for wear. 4. Inspect the pinion flange splines for wear. 5. Inspect the fit of the pinion flange on the pinion gear. 6. Inspect the sealing surface of the pinion flange for nicks, burrs, or rough tool marks which will damage the inside diameter of the pinion seal and result in an oil leak. 7. Inspect all of the parts for wear and replace as necessary. THRUST WASHERS, SHIMS, AND ADJUSTER SLEEVES INSPECTION 1. Inspect the shims and the thrust washers for cracks and chips. The damaged shims should be replaced with an equally sized service shim. 2. Inspect the adjuster sleeves for damaged threads. Replace if required. DIFFERENTIAL CASE ASSEMBLY ASSEMBLE (8.25 INCH AXLE) Tools Required J 8092 Universal Driver Handle - 3/4 in - 10 J 22761 Differential Side Bearing Installer. See Special Tools. J 22888-D Side Bearing Remover Kit. See Special Tools. Assemble 1. Lubricate the pinion and side gears using axle lubricant. Use the correct fluid. Refer to Sealers, Adhesives, and Lubricants.
2008 Chevrolet Silverado 1500 2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
