Fig. 36: Assembling Tripot Housing And Tripot Seal 9. Assemble the tripot housing and the tripot seal using the following procedure: 1. Pinch the swage ring (2) slightly by hand in order to distort it into an oval shape. 2. Slide the distorted swage ring (2) over the large diameter of the seal. 3. Place the tripot housing over the spider assembly. 4. Install the seal onto the tripot housing. 5. Align the tripot seal (1), with the swage ring (2) in place, over the flat area on the tripot housing (3).
2008 Chevrolet Silverado 1500 2008 DRIVELINE/AXLE Wheel Drive Shafts - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
|
