FAN GEARBOX (Cont’d) Disassembly NOTE: When repairing the gearbox order the following as needed. 1. Complete Assembly NOTE: The short housing is only available as an assembly. See the parts identification page NOTE: Be sure to count the number and thickness of shims during disassembly. Install the shims NOTE: Always replace seals during assembly. Replace the parts in the gearbox as needed. Remove the fan and blower housing mounting plate. (See Long Housing Loosen the set bolts (Item 1) [A] and remove the pulley Remove the long key (Item 3) [A]. Remove the four mounting bolts and the part number tag Remove the oil from the gearbox. Drill an 1/8 inch (3 mm) hole in the seal. Use a slide Remove the small snap ring [D]. Wear safety goggles to prevent eye injury W–2108–1186 AVOID INJURY OR DEATH Revised June 01 A P–03005 1 2 3 C P–02999 D P–02964 773 BICS Loader –7–15– Service Manual B P–02983 Part Number Tag |
