SPRING LOADED DRIVE BELT TENSIONER PULLEY Removal And Installation Remove the drive belt shield fastener (Item 1) [A]. Remove the belt shield [B]. Loosen and remove the tensioner pulley mounting bolt Installation: Tighten the bolt to 25–28 ft.–lbs. (34–38 Remove the belt tensioner pulley from the housing. Installation: Refer to Page 1–1 in the PREVENTIVE Reverse the removal procedure to install the drive belt Revised Jan. 99 A P–03967 1 C P–08760 1 773 BICS Loader –3–53– Service Manual B P–03969 |
