Section 10 BODY/FRAME Subsection 02 (FRAME) FRAME FRAME CLEANING NOTE: For bare aluminum frames use only Clean frame and tunnel with appropriate cleaners CAUTION: Never direct high-pressure water jet Touch up all metal spots where paint has been Seat Cleaning For all models, it is recommend to clean the seat CAUTION: Avoid use of harsh detergents such FRAME WELDING Aluminum Frame – No welds should be done on aluminum frame except if mentioned or required on a Bom- – Use ER-5356 rods for MIG or TIG welding. CAUTION: Before performing electrical weld- A32E0WB TYPICAL — MPEM UNPLUGGED CAUTION: If welding is to be done near plastic FRAME COMPONENT Drilling Procedure When drilling self-piercing rivets, use Superta- TM drill bit (P/N 529 031 800), available in a 5 mm (3/16 in) size and shipped in packs of 2. For proper drilling instructions and to prevent pre- Always use a variable speed electric drill. Partially drill rivet end — not the rivet head. Maintain a slow to medium speed at all times NOTE: To increase bit life, use Bombardier syn- CAUTION: High speed drilling will cause exces- A03H2FA TYPICAL Cut rivet using a chisel. Remove riveted part. Drive out remaining rivet head using a punch. mmr2004-Rev 347 |
