![]() 5-64 ENG • Tighten the connecting rod nuts. Refer to “INSTALLATION” in “CONNECTING • Remove the connecting rod and big end bear- ings. • Measure the compressed Plastigauge ® width e on the crankshaft pin. e 11. Select: • Big end bearings (P1 ~ P3) NOTE: • The numbers È stamped into the crankshaft web and the numbers 1 on the connecting rods are • “P1” ~ “P3” refer to the bearings shown in the crankshaft illustration. P1 P2 P3 Selection of bearings: • For example, if the connecting rod “P1” and the crankshaft web “P1” numbers are “6” and “2” Bearing size for “P1”: “P1” (connecting rod) – “P1” (crankshaft BIG END BEARING COLOR CODE 0 white 1 blue 2 black 3 brown 4 green 5 yellow 2 2 2 1 3 2 2 P1 P3 P2 È |
