4-69 POWR TR 2. Install: • Sprocket wheels NOTE: • When pressing the sprocket wheels onto the front axle, align the lugs on each sprocket wheel. • Position each sprocket wheel on the axle as shown in the illustration. È FX10/FX10RT/FX10RTR/FX10RTRA 102 mm 53.8 mm 39 mm 123 mm 27 mm 102 mm 39 mm 109.9 mm 199.4 mm 60 mm 143.3 mm 174.8 mm È 101 mm 157.1 mm (6.19 in) 166.1 mm (6.54 in) 222.2 mm (8.75 in) 105.5 mm (4.15 in) 29.6 mm (1.17 in) 29.6 mm (1.17 in) 27 mm (1.06 in) É 3. Place the track in the chassis. NOTE: For track with a direction of rotation mark a: Install the track with the mark pointing in the direc- È FX10/FX10RT/FX10RTR/FX10RTRA a È a É |
