2-73 INSP ADJ Compression damping force (Front side) * With the adjusting screw fully turned lightly in direction a CAUTION: • Do not continue to turn the adjusting screw in direction a after it stops. The shock absorber can be damaged and compression damping • Do not turn the adjusting screw in direction b more than 12 clicks. Even if the adjusting • Be sure to stop the adjusting screw at a posi- tion where there is a click. Adjusting 12 clicks out 6 clicks out 2 clicks out Minimum Standard Maximum Direction b* ← → Direction a Compres- Soft ← → Hard b a 1 |
