MPE 750 HO Snow

Spare Parts Catalogue

Page 2

910  Repair Kits

Part No Description

QTY

103320 Long Block Type 2

1

Long block with a black valve cover. Sub system parts like

starter and fuel rail are not supplied.

Part No Description

QTY

103334 Cylinder Head

1

The Repair Kit includes:

104249 Cylinder Head

1

100514 Bolt

M6x40 10.9

4

100094 Welch Plug

2

100228 Sleeve

8

101973 Rocker Arm Support 1

2

101974 Rocker Arm Support 2

2

100605 Bolt

M6x20 10.9

4

102327 Exhaust Valve

4

102542 Intake Valve

4

100262 Spring Pad

8

100081 Valve Spring

8

102316 Spring Cup

8

100129 Collet Valve

16

101921 Camshaft

1

100078 Camshaft Axle

1

102024 Rocker Arm Long

2

102023 Rocker Arm Short

2

100080 Rocker Axle

4

102992 Plug

1

102453 Stud

M8x38 8.8

8

400920 Fitting (total lenght 33mm) M8x1x12

1

401990 Fitting (total lenght 38mm) M8x1x17

1

100587 Seal

8x12x1 Al

2
