105

MAINTENANCE

Steering System

Steering Inspection and Adjustment

Check all steering system fasteners weekly and before a long ride.
Tighten any loose fasteners.

+

+

+

+

+

106

MAINTENANCE

Steering System

Ski Alignment

With the handlebars in a straight ahead position, and with vehicle
weight compressing the suspension, measure from the straight edge of
the skis at the center of the ski mounting bolt. The measurement
between the skis at point X should be 1/8" to 1/4" (3-6 mm) greater than
the measurement at point Y.

NOTE:

If the skis are misaligned, we recommend that your dealer correct the

alignment, since camber adjustment may also be affected.

WARNING

Improper ski alignment or adjustment may cause loss of steering control,

resulting in serious injury or death. Do not attempt to change the ski align-

ment or camber adjustment. See your Polaris dealer.

X

Y

10 in.

(25.4 cm)

10 in.

(25.4 cm)

107

MAINTENANCE

Steering System

n

Ski Skags

Check skags before each use of the snowmobile to ensure positive steer-
ing characteristics. Skags must be replaced when worn to half their orig-
inal diameter.

NOTE:

Carbide skags must be replaced if any abnormal wear or chipping is

found.

Skag Replacement

NOTE:

Some models are equipped with single skags. Other models are

equipped with dual skags.

1. Raise and support the front of

the snowmobile so the skis
are approximately 6" (15 cm)
from the ground.

2. Remove the attaching nuts

and pry the skag downward.

3. Remove the front end of the

skag.

4. Remove the rear end of the

skag.

5. Reverse the steps to install a

skag.

WARNING

Worn skis and/or skags will adversely affect handling. Loss of vehicle control

may result, causing serious injury or death.
See your dealer's studding chart for recommended skags. If you install longer

or more aggressive carbide skags than the original equipment, it may also be

necessary to add track studs to maintain proper vehicle control while turning

on hard-packed snow or ice.

Skag

108

MAINTENANCE

Steering System

n

Rail Slide Wear

For ease of inspection, all
Polaris rail slides have a
wear limit indicator groove
to indicate the minimum
permissible slide thick-
ness. Replace the rail
slides if they are worn to
the top of the groove at any
point along their length.
Failure to do so may result
in permanent damage to
the track or rails.

Replace when

worn to top of

groove

Minimum

Thickness
