Polaris ACE 570 (2018 year). Instruction - part 6

FEATURES AND CONTROLS

Cab Nets

Riding in this vehicle

without using the cab

nets (or doors, if

equipped) increases the

risk of serious injury or

death in the event of an

accident or rollover. Cab

nets (or doors) must be

used at all times. Make

sure all latches on both

sides of the vehicle are

secure before operating

the vehicle.
Always inspect cab nets and latches for tightness, wear and damage

before each use of the vehicle. Use the strap adjusters to tighten any

loose straps. Promptly replace worn or damaged cab nets and latches

with new cab nets and latches. Please see your authorized POLARIS

dealer.

Extreme Use Battery

An optional extreme use battery may be available for your model. If the

performance of the factory-installed battery is inadequate due to

operation in extreme cold or due to extended use of multiple electrical

accessories, please see your POLARIS dealer. Ask your dealer to

provide any installation procedures that may differ for an extreme use

battery.

Cab Net Latches

FEATURES AND CONTROLS

Fuel Cap

The fuel tank filler cap is located on

the right side of the vehicle near the

seat. When refueling, always use

either leaded or unleaded gasoline

with a minimum pump octane

number of 87 R+M/2 octane. Do

not use fuel with ethanol content

greater than 10 percent, such as E-

85 fuel.

Seat

Seat Adjustments

Always make sure the seat position allows for proper access and

operation of the brake pedal, throttle pedal and all other controls.
The seat release lever is located at the left side of the seat. Push the

release lever downward and slide the seat forward or rearward to the

desired position. Release the lever. The seat will lock into the new

position.

Seat Removal

1. Push the seat release lever

downward and slide the seat

forward until it slides off the

frame.

2. Lift the seat away from the

vehicle.

3. Reverse the procedure to reinstall

the seat.

Fuel Cap

Seat Release

Lever

FEATURES AND CONTROLS

Seat Belt

This POLARIS vehicle is equipped with three-point lap and diagonal

seat belts. Always secure the seat belt before riding.
To wear the seat belt properly, follow this procedure:
1. Pull the seat belt latch downward and across your chest toward the

buckle at the inner edge of the seat. The belt should fit snugly across

your hips and diagonally across your chest. Make sure the belt is not

twisted.

2. Push the latch plate into the buckle until it clicks.
3. Release the strap, it will self-tighten.
4. Press the red release latch on the buckle to release the seat belt.

Seat Belt Inspection

Inspect all seat belts for proper operation before each use of the vehicle.
1. Push the latch plate into the buckle until it clicks. The latch plate

must slide smoothly into the buckle. A click indicates that it's

securely latched.

2. Push the red release latch in the middle of the buckle to make sure it

releases freely.

3. Pull each seat belt completely out and inspect the full length for any

damage, including cuts, wear, fraying or stiffness. If any damage is

found, or if the seat belt does not operate properly, have the seat belt

system checked and/or replaced by an authorized POLARIS dealer.

4. To clean dirt or debris from the

seat belts, sponge the straps

with mild soap and water. Do

not use bleach, dye or

household detergents. Use a

garden hose to flush out the

retractor and latch housing

regularly.

Retractor

Housing

Latch

Housing

FEATURES AND CONTROLS

Switches

Turn Signal Lever

Before turning, activate a turn

signal to alert others of your

intentions. Check turn signal

lamps before each ride.

Tip: The key must be in the ON

position to activate the turn

signals.

Move the turn signal lever

downward to signal a left

turn. The left turn signal

lamps in the taillight and

below the front headlight will

flash. The turn signal

indicator in the gauge will

also flash.
Move the lever upward to signal a right turn. The right signal lamps and

indicator will flash.
Return the lever to the center position to end the signal.

High Beam Switch

The headlight high beam is controlled by the turn signal lever. To switch

the headlights to high beam, move the lever forward, toward the

console. Move the lever rearward to switch the headlights to low beam.

Horn Switch

The horn switch is located on the turn signal lever. Press the tip of the

turn signal lever inward to sound the horn.

Horn

Switch

Turn Signal/Flasher

Indicators

Turn Signal Lever
