66

MAINTENANCE

Lubrication

Front Suspension

The front suspension does not require lubrication.

Rear Suspension

Lubricate the suspension pivot shafts with POLARIS Premium All Sea-
son Grease at the intervals outlined in the Periodic Maintenance Table
beginning on page 62 and before seasonal storage. When operating in
heavy, wet snow conditions, lubricate every 500 miles (800 km).

Lack of lubrication will adversely affect your ride and the life of the sus-
pension. For more information about suspension lubrication and adjust-
ments, see your POLARIS dealer.

IQ Rear Suspension (121)

IQ Comfort Rear Suspension (136)

X

X

X

X

X

X

X

X

67

MAINTENANCE

Lubrication

Driveshaft Bearing

Inject grease into the fitting on the
speedometer sensor housing until
grease purges from the seal on the
inside of the tunnel.  This should
take approximately two pumps.  Do
not use more than four pumps.

Throttle Cable

Lubricate the throttle cable lightly
with grease or oil. With the engine
off, turn the handlebars to the left
and lubricate liberally as shown.

Choke and Choke Cable

Lubricate the choke slide and cables
lightly with oil or grease. Before
turning the engine off, operate the
choke intermittently to draw mois-
ture out of the choke plunger area
and reduce the possibility of the
choke becoming frozen.

X

X

X

68

MAINTENANCE

Lubrication

Chaincase Oil

Check the chaincase oil level at the
intervals outlined in the maintenance
charts beginning on page 62. The sight
glass (1) is located on the lower rear of
the chaincase. Maintain the oil level at
or slightly below the center of the sight
glass (2). Change the chaincase oil after
the first 500 miles (800 km), then every
1000 miles (1600 km) or seasonally.

POLARIS recommends the use of
POLARIS Synthetic Chaincase Lube.
See page 102 for the part numbers of
POLARIS products.

Oil Check

1. Position the vehicle on a level sur-

face.

2. View the oil level at the sight glass.

3. Remove the fill plug (3) and add the

recommended oil as needed. Do not
overfill.

4. Reinstall the fill plug, making sure it

is seated properly.

1

3

2

69

MAINTENANCE

Lubrication

Chaincase Oil

Oil Change

1. Position the vehicle on a level surface.

2. Remove the drain plug (4) and drain

the oil into a drain pan. Allow the oil
to drain completely.

3. Clean off all metal shavings from the

plug.

4. Install a new sealing washer on the

drain plug.

Tip: The sealing surfaces on the drain plug and the oil tank should be clean and

free of burrs, nicks or scratches.

5. Reinstall the drain plug. Torque to 6-10 ft. lbs. (8-13 Nm).

6. Remove the fill plug. Clean off all metal shavings from the plug.

7. Add 9 oz. (265 ml) of the recommended oil. Do not overfill.

8. Reinstall the fill plug, making sure it is seated properly.

4
