JAC-J7. Service manual - part 16





-05

Driver inspection bill

Inspect the inner vehicle, outer vehicle
and engine room regularly to keep the
vehicle safe and reliable.
Outer vehicle
淫 Tyre
The expansion is mild (see 野wheel and
tyre冶)
There is no crack on the tyre side and
tyre surface.
There is no foreign matter in the tyre
thread.
淫 Wheel
The bolt and nut are tightened. (See
section VI 野How to Replace the Flat
Tyre冶)

淫 Lamp
All the traveling lamp, headlamp, rear
lamp, width showing lamp, steering sig鄄
nal lamp, stop lamp and fog lamp can
work normally.
淫 Oil fluid
Check the oil level of all the fluid tanks
under the engine cover is suitable.
淫 Windshield wiper of Front wind鄄
screen
Check the state of the wiper arm and
wiper blade (including windshield wiper
of rear window, such as equipment)
Inner vehicle
淫 Steering
Check whether the steering wheel is
over loosened (idling).

淫 Parking brake
Ensure the travel of the control rod of
the parking brake is suitable.
淫 Console
Check whether the operation of the all
the console instruments, control button
and warning lamp is normal.
淫 Rear mirror
Ensure that all the reflecting surfaces of
three rear mirrors are in good condition
and clean.
Check whether all the rear mirrors can
be readjusted.
淫 Controlling
Check whether the clearance between
the brake pedal and the clutch pedal is
suitable.

MO TORS

Notes

Even if th e engine is not running, the
engine cooling fan inside the engine
cabin may be started and cause dam鄄
age to you. So, the hands, dresses and
tools shall be kept away from the fan in鄄
side the engine cabin.

-04

淫 In order to avoid accidental person
damage, turn off the ignition switch and
pull out the key when operating under
the engine cover, unless the mainte鄄
nance procedure requires the engine to
keep running. If the engine must be
kept running when working, take off the
loose coat and take away the jewelries,
otherwise, they will be winded-up at the
moving components and cause dam鄄
age.

Inspecting the inner components of the
engine cabin

Before any inspection of the engine, ex鄄
tinguish the engine and stop the fan
from working to avoid any damage by
the cooling fan.
Besides, the voltage of the electronic
ignition system is higher than that of the
common system, so, touch the live
components of the vehicle is very dan鄄
gerous when the ignition is on.

Notes

If the combustibles fall on the engine
components of high temperature, it may
cause fire. These combustibles include
fuel, oil, coolant, brake fluid, front
windscreen washing solution, etc, and
plastic and rubber. The fire may cause
damage to you and others. So, take
care to avoid the combustibles flatter鄄
ing or falling on the un-cooled engine.

-07

Engine oil filling

If the oil pressure warning lamp on the
combined instruments of the console is
on, it shows that inspection of the en鄄
gine oil level is immediately required
For details, see Section III 野Oil Pressure
Warning Lamp冶. You should check the
engine oil level regularly, for the warning
lamp only functions as warning.

Check the engine oil level

You爷d better check the engine oil when
filling oil. The oil should be cooled in or鄄
der to get accurate reading.
1. The vehicle shall be on the flat floor.
2. Shut off the engine, and wait for a
minute to make the oil flow to the stock
solution tray. If not, the actual berth will
not be shown on the oil rule.

3. Draw out the oil rule, insert back to
the place after wipe clean with paper
and cloth. Draw out again and keep the
tip downwards, check the berth.
When to fill engine oil

4. If the oil level is at the position of
mark hole (A) at the lower part of the oil
rule or lower than this position, you
should fill oil. In this section, we will
show which oil type shall be used.

MO TORS

-06

1. Engine oil filler cap
2. Engine oil rule
3. Engine air filter//filter element
4. Stock solution tank for engine coolant

5. Stock solution tank for power steering
fluid
6. Stock solution tank for front wind鄄
screen washing solution

7. Stock solution tank for brake fluid
8. Storage battery
9. Fuse box of engine cabin

Engine cabin

Notes

This job requires special skills, tool and
equipment.
Before trying to undertake this job, you爷
d better be sure that you are up to this
job.
It is suggested that it shall be done by
Special After -sale Service Center of
Jianghuai Automobile Co., Ltd.
Otherwise, it will cause damage or in鄄
jury to the vehicle.

-09

Notes

The normal operation of the engine re鄄
quires fresh air.
Prohibit driving the vehicle without
mounting air filter/filter element.
Driving without mounting air filter ele鄄
ment will cause damage to the vehicle.

The severe conditions include but not
limit to the following:
淫 Always cold start-up
淫 Frequently stop when the traffic is
not smooth
淫 Always travel for a short distance
淫 Always travel when the outer vehi鄄
cle temperature is lower than the ice
point
淫 Idling for a long time
淫 Always travel at low speed
淫 Travel under dusty condition

Air filter/filter elements

According to the maintenance regulation
introduced in this manual, check and
replace air filter element regularly.

MO TORS

-08

5. Do fill proper quantity of oil to make
the berth in the range of normal opera鄄
tion, that is, the oil rule is in the middle
of two mark holes. Insert the oil rule
back completely after finishing filling oil.
Which kind of engine oil shall be used?
It is suggested to use the following oil
types:
1. -20益 耀30益 SAE 10W/30 Grade
SG
2. -30益耀20益 SAE 5W/40 Grade SG
Engine oil additive
Do not add any substance into the oil.
The recommended oil can completely
ensure the engine run well and protect
the engine.

Replacing the Engine Oil and Lubricating
Oil Filter
The engine oil will lose lubricating ca鄄
pability after being polluted. Do replace
the engine oil as the maintenance regu鄄
lation. Replace the lubricating oil filter
each time when replacing the engine oil.
Under severe condition, the replacing
time of oil and lubricating oil filter shall
be shorter than the time stated in the
standard maintenance regulation.

Notes

The engine oil is irritative, it will cause
illness or death after swallowing it.
Keep away from the children.
Keep the skin from touching the oil fre鄄
quently or for a long time.
Wash the touched position with soap
and water or washing fluid.

Notes

Over filling of oil will affect the operation
of the engine.
Prohibit exceeding the MAX mark on
the oil rule.
Over filling will cause damage the vehi鄄
cle, the reasons are:
淫 Increase the consumption of engine oil
淫 The oil will spill from the ignition plug
淫 Alotofcarbonwillassembleontheengine

淫 Ensure the warning lamp and in鄄
strument to work normally.
Using which kind of coolant
Use 43/57 clean drinking water and the
coolant mixture in compliance with the
requirements of Jianghuai Automobile
Co., Ltd. This kind of coolant will not
cause damage to the aluminium compo鄄
nents.

Notes

When the engine is in heat state, do not
fill coolant, and fill after the engine be鄄
come cold. Otherwise, it will cause
great damage to the engine.

Notes

Try to use the anti -freezing solution of
the same brand. Different brand anti -
freezing solutions have different making
recipe. If mixed to use, chemical reac鄄
tion may appear in different additives,
which will invalidate the additives; the
effective period of most anti-freezing so鄄
lutions is two years (the period of some
products will be longer), make sure that
they are in effective period when filling;
replace regularly, generally, replace
once for every two year or every ten
thousand kilometers. For the taxi, they
need replace more frequently. Let out all
the old fluid when replacing, clean the
cooling system and then replace for the
new fluid; avoid using with water.

-11

The traditional inorganic anti -freezing
solution can not be used with water, be鄄
cause it will deposit and seriously influ鄄
ence the normal function of anti-freez鄄
ing solution. The organic anti -freezing
solution can be used with water, but not
too much water. Although glycol itself is
not poisonous, with the existence of an鄄
ti-rust solution, the anti-freezing solu鄄
tion becomes poisonous. Therefore, the
vehicle owner shall store the anti -
freezing solution in the special contain鄄
er which the children can not reach.
When filling anti-freezing solution, pay
attention not to splash the anti-freezing
solution on the vehicle paint, for it will
cause damage to the paint film; and
pay attention not to let the anti-freezing

MO TORS

Clean the air filter

If the air filter element is dirty, clean it as
the following orders:
1. Flick the air filter elements to throw
away the floating dust
2. Clean the inner housing of the air fil鄄
ter
3. Cover the filter housing with wet cloth
when cleaning the filter element

4. Clean the filter element with com鄄
pressed air in the opposite direction to
the normal air flow
Maintenance regulation
See 野Section VIII Maintenance Plan冶.

Engine coolant

The following part has introduced the
cooling system of this vehicle and the
method of adding coolant when the
coolant level is low. If there is overheat
failure on the engine, see 野Overheated
Engine冶.
The mixture of 43/57 clean drinking water
and proper coolant has the following
functions:
淫 Anti-freezing, the lowest tempera鄄
ture can be -45益;
淫 Anti -boiling, the highest tempera鄄
ture can be 110益;
淫 Anti-rust; (Preservative agent shall
be added in it.)
淫 Help to keep normal engine ro鄄
tating speed;

-10

Normal air flow
