JAC-J7. Service manual - part 6
Notes
When the car is running, it is very dan鄄
gerous to sit on the seat with inclined
backrest. Even if you have already tied
the safety belt, it won爷t act if your body
is so much inclined; neither will be the
shoulder belt as it cannot closely cling
to your body. The shoulder belt lies in
your front side, and when the car col鄄
lides, you might clash onto the shoulder
belt, injuring your neck or other body
parts. The hip belt could neither act, for
during collision process, this belt will
slide to the upper side of your ab鄄
domen. The effect of hip belt still exists
but not on your hipbone position, which
will cause serious internal injuries.
Pillow
Adjust the pillow height and make its
upper side approach your crown as
much as you can, so as to minimize the
chances of your neck getting injured
during the car collision.
Lift: pull up the pillow and you can ad鄄
just the pillow height.
In order to protect the passengers in鄄
side the car when driving, the seat
backrest should be at vertical posi鄄
tion. Then lean against the back part
of the seat as much as you can and
correctly wear the safety belt.
-18
Descend: While pressing down the lock鄄
ing release button, press the pillow down.
To dismount the pillow, please fully pull
up the pillow, and then press the re鄄
lease button and lift the pillow from in鄄
side the guiding sleeve.
Before driving, the pillow should be re鄄
assembled and readjusted to the origi鄄
nal position.
Rear seat
The two exterior seats in rear row and
the middle seat are all equipped with
three-point safety belt.
To use the middle handle of rear seat,
pull out the middle handle with cup sup鄄
port installed as shown in the above pic鄄
ture.
-19
