JAC-J7. Service manual - part 2





-07

Idle speed
Even at idle speed, engine burns oil
and produces noises. The fuel con鄄
sumption of a 5-minute idle time equals
to traveling about 1km. Therefore, the i鄄
dle time during parking should be
shortened as possible.
High speed driving
Excess accelerated driving can lead to
exorbitant fuel consumption and louder
noises. Even if the acceleration pedal is
released somewhat, fuel will be saved
while vehicle speed is not reduced no鄄
tably. The higher the speed the vehicle
travels, the louder the tire and wind
noises will be. When vehicle speed in
high gear exceeds 70km/hr, the noise
from the tire will be clearly evident.
Noises from a vehicle running at 150km/

hr are equivalent to noises of 4 vehicles
at the speed of 100km/hr or 10 vehicles
at the speed of 70km/hr.
Door
Close the door tenderly.
Tire pressure
Too low tire pressures can increase your
fuel consumption, accelerate wearing of
tires, add up to your cost of use and af鄄
fect driving safety while too high tire
pressures will reduce the adhesiveness
of wheels and increase body vibration,
thus affecting driving safety and com鄄
fort. Please check tires on a regular bi鄄
weekly basis.

Loading
Unnecessary loading can add up to fuel
consumption, especially during acceler鄄
ation on urban road, running on urban
road with the loading of 100kg will add
about 0.5L/100km in terms of fuel con鄄
sumption.

MO TORS

Awareness in environment protection
during driving
Awareness in environment protection
should be kept during driving. Thank
you for your efforts in lowering noises
and reducing waste gases. This is not
only energy saving, but also favorable
for improving life quality.
Unnecessary speedy acceleration will
obvious level up fuel consumption, tire
noises at starting and excessively high
engine idling rotation can increase noise
level by as much as four folds.
Shift to higher gears as possible. A vehi鄄
cle running at 2nd gear can produce
noises equal to noise made by 3 vehi鄄
cles at 4th gear at the speed of 50km/hr.

The first 1,000km

for new vehicles are crucial in terms of
their

durability

and

performances.

Please refer to relevant information.
Keep speed balanced
Shift to higher gears as possible.
In urban traffic, 4th t gear is often ap鄄
plied. The fuel consumption of vehicles
at 3rd gear can be 30% more than
those at 4th gear when running at a
speed of 50-80km/hr and more noises
are released to environment. The fuel
consumption of a vehicle running at 4th
gear can be over 20% more than that at
5th gear at a speed of 70-90km/hr.
Urban Traffic
Frequent stopping and moving, like at
cross-roads with traffic light control, will

prominently increase fuel consumption
and noise level. Be always cautious of
the traffic ahead of you to avoid unnec鄄
essary braking. Choose the roads where
traffic is smooth as possible. Be careful
of brake distance and do not frequently
apply brake or acceleration pedal in or鄄
der to reduce noise contamination, ex鄄
cessive emission and fuel consumption,
especially when driving in residential
areas or during night time.

Friendly Tips

If you have to park and move your
vehicle on urban road often, you are
advised to run on the highway for
100-200km at an interval of 5,000km
driving to effectively decrease carbon
residuals and engine shivering.

-06

Repair and check-up
During the repair, production and in鄄
spection processes, JAC adopts envi鄄
ronment friendly materials.
Do not repair commission and/or in鄄
spect the engine on your own. The rea鄄
sons are as follows:
淫 Due to unfamiliarity to equipment,
operations against the current environ鄄
ment protection regulations may hap鄄
pen.
淫 Recyclable parts are not recycled
for reuse.
淫 Contact to certain materials may do
harm to the skin.

Inappropriate repair waives up

rights in claims.
Please turn your vehicle in a designated

after -sales service center for mainte鄄
nance purposes.

Wish you a pleasant driving!

-08

-01

Chapter II Technical Parameters and Vehicle Identification

Main vehicle dimensions

2-02

Vehicle quality parameters

2-03

Main fluids

2-04

Main engine parameters and performances

2-04

Power performance index

2-05

Gear ratio of transmission

2-05

Front and rear wheel alignment parameters (unloaded)

2-06

Wheel, tire specifications and cold state pressure

2-06

Vehicle VIN

2-07

MO TORS

-03

Number of Passengers

Person

5

Curb Weight

kg

1,470

Loaded Weight

kg

1,845

Front Axle Load (Curb)

kg

885

Rear Axle Load (Curb)

kg

585

Front Axle Load (Loaded )

kg

995

Rear Axle Load (Loaded )

kg

850

Items

Unit

Parameter

2.0L

2.4L

Vehicle quality parameters

MO TORS

-02

Main vehicle dimensions

Items

Unit

Parameter

Length

mm

4,865

Width

mm

1,805

Height (Unloaded)

mm

1,450

Wheel Base

mm

2,790

Front Tread

mm

1,565

Rear Tread

mm

1,560

Boot Capacity

dm

3

(h)

550

Min. Ground Clearance

mm

125

Approaching Angle

(毅)

15

Departure Angle

(毅)

16
